Products

Standard Paper Tray & BypassStandard Capacity: 500 sheets Bypass Tray (Single Sheet/Manual Feed): 130 sheets Paper Sizes: Max A3, (11 times 17^{prime prime}), Min A5Paper Weight: 60 to 256 gsm Expandable Tray Configurations (Optional)To increase your capacity, you can add up to a 3-Tray Module to get a 4-tray setup:1-Tray Module: Adds 500 sheets (Total capacity: 1,000 sheets)3-Tray Module: Adds 1,596 sheets (Total capacity: 2,096 sheets) General Device Specifications: Speed: 25 pages per minute (PPM) for both color and monochrome. Print Resolution: 1,200 × 2,400 dpi. Memory & Storage:

Print and copy speeds of 20 pages per minute (ppm). Paper Capacity: Main Standard Tray: 500 to 520 sheets; Bypass Tray: 100 to 110 sheets. Supported Paper SizesMaximum Size: A3 (11 x 17 inches)Minimum Size: A5 Supported Paper Weight: Main Tray: 60 to 256 GSM (Grams per Square Meter); Bypass Tray: 60 to 216 GSM Core Colour Specifications: Print Resolution: 1,200 × 2,400 DPI achieved with LED printhead. Colour Technology: Utilises Super EA-Eco toner for vibrant colours and Digital Correction Technology (IReCT) to reduce colour misregistration. Print Speed: 20 ppm in both full colour and monochrome.

The Fujifilm Apeos 4570 is a high-speed, A3 monochrome multifunction printer. It delivers print and copy speeds of up to 45 ppm, scan speeds up to 160 ppm, and boasts a print resolution of 1200 x 2400 dpi Key Specifications:Functions: Standard Print, Copy, Scan; Optional Super G3 Fax.Paper Sizes: Supports from A5 up to SRA3.Paper Capacity: 500-sheet tray + 90-sheet bypass tray (expandable with optional high-capacity feeders).Memory/Storage: 4GB RAM & 128 GB SSD.Display: 10.1-inch tilted color touchscreen.First Page Out: Approx. 3.6 seconds.

specifications SPDF Speed 35ppm printing resolution 1200 x 2400 dpi scan resolution 600 x 600 dpi paper capacity standard A3 520 Sheets x 2 Tray + 840 Sheets + 1230 sheets Bypass Tray 90 sheets Size 12.6 x 19 storage capacity; with 4 GB RAM, 128 GB SSD.

Specification SPDF Speed 30ppm paper capacity A3 standard 520 sheets x 2 - tray + 840 sheets + 1230 sheets Bypass Tray + 90 sheets Storage Space 4Gb Ram 128 GB SSD Size 12.6 x 19 print Resolution 1200x 2400 Dpi scan resolution 600 x 600 dpi

Throughput at 2400 dpi2,3 plates per hour (pph) S speed = 22 pph F speed = 28 pph For plate size 724 x 838 mm S speed = 16 pph F speed = 22 pph For plate size 1030 x 838 mm Repeatability ± 5 microns between two consecutive exposures on the same plate left on the drum Accuracy ± 20 microns between two plates imaged on the same device Registration ± 25 microns between image and plate edge Workflow connectivity Standard KODAK Print Console with TIFF Downloader Software included; connects to KODAK PRINERGY Workflow and most third-party workflow systems. The optional KODAK Mobile CTP Control App lets you monitor CTP devices from your mobile device. Imaging specifications T400 Plate setter . Resolution 2400 dpi or 1200 dpi Screening 200 lpi max line screen; Optional: 36-micron KODAK STACCATO Screening Maximum plate size: around x along drum4 838 x 990 mm5 Standard: 838 x 1,143 mm5 Auto Unload/Autoloader: 838 x 1,118 mm Minimum plate size: around x along drum4 Standard: 267 x 215 mm Auto Unload/Autoloader: 330 x 270 mm6 Standard: 267 x 215 mm Auto Unload/Autoloader: 330 x 270 mm6 Maximum image area: around x along drum 827.9 x 990 mm Standard: 827.9 x 1,143 mm Auto Unload/Autoloader: 827.9 x 1,118 m

FeatureQ400 PlatesetterQ800 PlatesetterMax. Plate Size267 × 394 mm up to 450 × 625 mm305 × 305 mm up to 838 × 1,143 mmThroughput (at 2400 dpi)Up to 43 plates per hourUp to 41 plates per hour (Standard Auto Unload)Imaging Technology830 nm thermal external drum with SquareSpot830 nm thermal external drum with SquareSpotResolutions1200 dpi and 2400 dpi standard (UHR model goes up to 12,800 dpi)1200 dpi and 2400 dpi standard (UHR model goes up to 12,800 dpi)Registration Accuracy± 5 microns between exposures± 5 microns between exposuresAutomation LevelsSemi-automatic, Auto Unload, AutoloaderSemi-automatic, Auto Unload, Autoloader, MCU/SCU

Machine Type Digital Colour Cut-sheet Press Core Functions Print, Copy, Scan, Send, Store Processor Speed 1.8 GHz, 1.3 GHz Dual Control Panel 25.65cm (10.1in) Memory 6GB Interface Connection NETWORK Network Protocols Standard: 1000Base-T/100Base-TX/10Base-T Paper Input (Standard) Standard: 1 100 sheets 550 sheet Paper Cassette x 2 Maximum: 11 100 sheets Engine 550 x 2, Multi-drawer Deck (1 500 + 1 500 + 2000) x 2 Paper Supply Capacity (A4, 80 g/m²) 11 100 sheets Finishing Capabilities Collate, Group, Offset, Staple, Saddle Stitch, Hole Punch (multiple patterns), Document Insertion, Fold (C-, Z-, Half, Double parallel, Accordion-Z fold), Trimming Supported Media Types Thin (52-63g/m²), Plain (64-105g/m²), Recycled, Colour, Thick (106-400g/m²), Coated (70-400g/m²), Embossed, Bond, Transparency, Label, Pre Punched, Letterhead, Index, Transparent film, Translucent film, Envelope, Synthetic, Magnetic Supported Media Sizes A3S, B4S, A4L, A4S, B5S, B5L, A5S, A5L, A6S, SRA3S, 27.94 x 43.18cm (11 x 17in) S, LGLS, LTRL, LTRS, EXE_L, STMTS, 30.48 x 45.72cm (12 x 18in) S, 33.02 x 48.26cm (13 x 19in) S, 8KS, 16KL, 16KS, Envelope, Custom size (Cross track: 100~330.2mm, In track: 148~487.7mm), Long Sheet (210.0 x 487.8 - 330.2 x 1 300.0mm)

Canon imageRUNNER ADVANCE DX 8986 is a heavy-duty, floor-standing A3 monochrome laser multifunction printer (MFP) designed for high-volume corporate and commercial printing. Key specifications for the DX 8986 include:Speed: Up to 86 ppm (pages per minute) for A4 and 44 ppm for A3. Resolution: 1200 × 1200 DPI for printing and 600 × 600 DPI for scanning and copying.Paper Capacity: Standard 4,200 sheets, expandable up to 7,700 sheets.Media Weight: Handles paper weights ranging from 52 g/m² to 256 g/m².Scan Speed: Single-pass duplexing up to 270 ipm (images per minute).Memory & Storage: 4 GB RAM and a 256 GB SSD (upgradeable to 1 TB SSD).

Model Name/Number Canon imagePRESS V900 Brand Canon Printer Speed 90 A4 pages/ minute (Color/ B&W) Paper GSM 52-350 g/m2 (GSM) Printing Resolution 2400 X 2400 dpi, 190 LPI Input Tray Tray 1-3 (550 Sheets, 330 X 487 mm, 80 g/m2 (GSM)) | POD Deck Lite (3500 Sheets, 330 X 487 mm, 80 g/ Std. Paper Size 330 X 487 mm, (350 g/m2 (GSM)) (Auto Duplex) from Bypass or POD Deck L Banner Paper Size 330 X 762 mm from Bypass (350 g/m2 (GSM)) (Auto Duplex) | 330 X 762 mm from POD XL (300 g/m2 (GSM)) Finisher Options Output Tray/ Finisher Options Fiery P400 (Fiery System FS500) with Hot Folders & Job Flow Base for Job Management, Color Management & Va Feeding & Registration Mechanism Enhanced Air Assist with POD Deck Lite | Duplex Demagnification

Specifications ; Technical specifications - Model 14; Paper width max: 350 mm Paper Thickness: 100-500 gsm Lamination speed: up to 20mtrs / min Air Pressure: 8 Bar [ Compressed ] Power - 3.5 kW / 220 Volts / 50 HZ Net WEIGHT - 200 KGS Dimensions [ w x H X L ] ; 935 x 2300 x 1500 mm

Specifications: Technical Specifications; MRS 850-A Paper Size [ Max] - 850 x 1100 mm Paper size [ Min] -300 x 300 mm Lamination Size [ Max] - 812 x 1100mm Lamination Size [ MIN] - 300 x 300mm Paper Thickness -90-500 g/m2 Pile THICKNESS - 90-500/ GM2 Lamination speed [ cold] - 70 Meters/minute Lamination Speed [ Thermal ] - 50 Meters / minute Air Pressure: 8 bar [compressed]
