GENERAL SPECIFICATIONS Technology 830 nm platesetter with KODAK SQUARESPOT Imaging Technology Load/unload systems Semi-automatic plate loading and unloading. PERFORMANCE SPECIFICATIONS Throughput at 2400 dpi1,2 for plate size 1,030 x 800 mm, portrait mode F speed = 11 plates per hour X speed = 19 plates per hour W speed = 31.2 plates per hour Resolution Standard: 2400/1200 dpi Optional: 2540/1270 dpi High-Resolution Options: 4800 or 5080 dpi Screening 450 lpi max line screen Optional: 20- or 25-micron KODAK STACCATO Screening Maximum plate size: around drum x along drum4 1,325 x 1,650 mm Minimum plate size: around drum x along drum4 394 x 394 mm Maximum image area: around drum x along drum 1,314.9 x 1,650 mm.

High-quality, long-run plate for sheet-fed, packaging, web, and all UV print applications Gauge 0.20, 0.30, and 0.40 mm Spectral sensitivity Resolution 1 to 99% @ 200 lpi and FM20 capable Up to 450 lpi is possible, dependent upon the capability of the imaging device. 800 – 850 nm RUN LENGTHS OF UP TO 400,000 IMPRESSIONS ON WEB PRESSES 1 to 99% @ 200 lpi and FM20 capable Up to 450 lpi is possible, depending upon the capability of the imaging device.

Q400 Platesetter F speed = 30 pph X speed = 43 pph Autoloader/SCU/MCU: F speed = 33 pph X speed = 50 pph W speed = 75 pph For plate size 838 x 724 mm (around x along drum). Standard and Auto Unload: F speed = 22 pph X speed = 34 pph Autoloader/SCU/MCU: F speed = 24 pph X speed = 41 pph W speed = 66 pph For plate size 838 x 1030 mm (around x along drum) Q800 Standard and Auto Unload: F speed = 22 pph X speed = 34 pph Autoloader/SCU/MCU: F speed = 24 pph X speed = 41 pph W speed = 66 pph For plate size 838 x 1030 mm (around x along drum) Q400 Platesetter Resolution Standard: 2400/1200 dpi Optional: 2540/1270 dpi High-Resolution Options: 4800 or 5080 dpi Screening 450 lpi max line screen; Optional: 25-, 20- or 10-micron KODAK STACCATO Screening
