Specifications: Maximum Web/Lamination Width: 1080mm to 1600mm (5 feet).Laminating Speed: High-capacity laminators often reach speeds of 50 to 70 meters per minute.Pressure & Feed Mechanism: Uses automatic pneumatic pressure adjustment (often via air compressors) and automated, motorized sheet feeders.Core Specifications: Often handles large 6-inch film cores.Power Requirements: Heavy-duty machines operate on industrial 415V (3-phase) power, requiring between 9 kW and 12.5 kW.

Specifications: Lamination Width: Ranges widely from 350mm (13 inches) up to 750mm (30 inches) depending on the model.Speed: Adjustable laminating speeds, typically spanning from 600 mm/min to 7 meters/minute, ensuring smooth, bubble-free finishes.Rollers: Standard configuration includes 2 to 4 heavy-duty rollers. Media Thickness: Accommodates paper/cardstock thicknesses between 100 gsm and 400+ gsm, with adjustable gaps (often up to 5mm–10mm) for thicker substrates like sunboard or foam board.Film Capability: Supports thermal (hot), BOPP, and pressure-sensitive (cold) films with thicknesses of 25 to 250 microns.

LOHMANN FLEXO TAPES, featuring the renowned DuploFLEX® range, are premium double-sided plate mounting tapes designed for high-performance flexographic printing. Engineered to deliver exceptional print quality, reliable plate adhesion, and consistent press performance, these tapes are ideal for flexible packaging, labels, corrugated board, and other demanding flexographic printing applications. Manufactured with advanced foam technology and high-performance acrylic adhesives, LOHMANN FLEXO TAPES provide excellent cushioning, controlled dot gain, and uniform pressure distribution for superior image reproduction. Their innovative construction ensures bubble-free plate mounting, residue-free removal, and dependable adhesion throughout long production runs, helping printers improve efficiency while reducing downtime and waste. Available in multiple foam hardness levels and thicknesses, the DuploFLEX® range can be matched to different print requirements, from fine halftones and detailed graphics to heavy solid ink coverage. These tapes are compatible with UV, solvent-based, and water-based inks, making them a versatile solution for modern flexographic printing operations.
